specification
1 the main function of the machine glue , edge cutting , fine trim
2 the machine can work with all straight edge of PVC ,ABS, plastic foil,wood skin, etc
3 this machine very easy for operate and high quality
4 the working is automatic
5 the glue pot use high quality Europe structure, make the job more quick and save time.
model | BJF115M |
Board length | Min.280 (PVC) mm |
Board width | Min.90 mm |
Board thickness | 10~45 mm |
Edge width | 12~48 mm |
Edge thickness | 0.4~3 mm |
Feed speed | 6.4 m/min |
power | 2.74 kw |
Air pressure | 0.6 mpa |
size | 2320×800×1070 mm |
weight | 400 kg |
